The RevoDrive family gets its edge by eliminating the SATA II (3Gbps) bottleneck and leveraging a PCIe x4 interface, delivering superior speeds over 740MB/s sequential speeds and random small file writes up to 120,000 IOPS, nearly triple the throughput of other high-end SATA based solutions. The RevoDrive X2 uses an onboard RAID 0 design by employing four SandForce-1200 controllers to maximize data access and bandwidth.
Specifications:
- Available in 100GB to 960GB (1TB) capacities
- PCI-Express interface (x4)
- For use as primary boot drive or data storage
- 4 x SATA
- Internal RAID 0
- 181.07 (L) x 21.59 (W) x 125.08mm (H)
- Shock Resistance: 1500g
- Seek Time: 0.1 ms
- Operating Temp: 0°C ~ +70°C
- Storage Temp: -45°C ~ +85°C
- Power Consumption: 4.3W Idle, 8.3W active
- MTBF: 2,000,000 hours
- Compatible with Windows XP 32/64, Vista 32/64, Windows 7 32/64
Performance:
- 100GB-160GB Max Performance:
• Read: Up to 740 MB/s
• Write: Up to 690 MB/s
• Sustained Write: Up to 550 MB/s
• Random Write 4KB (Aligned): 100,000 IOPS
- 240GB-960GB Max Performance:
• Read: Up to 740 MB/s
• Write: Up to 720 MB/s
• Sustained Write: Up to 600 MB/s
• Random Write 4KB (Aligned): 120,000 IOPS
