Sabertooth X58 - Forged for Ultimate Reliability
- Intel® LGA1366 socket for Intel® Core™i7 Processor Extreme Edition / Core™i7 Processor
- Intel® X58/ ICH10R
- CeraM!X Heatsink Coating Tech. - Larger area for heat dissipation with the revolutionary ceramics-coating technology
- TUF Components (Alloy Choke, Cap. & MOSFET; certified by military-standard) Certified for Tough Duty
- E.S.P. [Efficient Switching Power Design] - Optimal power efficiency for key components
- True USB 3.0 & SATA 6Gb/s Support
Specifications:
- CPU: Intel® Socket 1366 Core™ i7 Processor Extreme Edition/Core™ i7 Processor. Supports Intel® Turbo Boost Technology
- Chipset: Intel® X58 /ICH10R
- System Bus: Up to 6400 MT/s ; Intel® QuickPath Interconnect
- Memory: 6 x DIMM, Max. 24 GB, DDR3 1866/1800/1600/1333/1066 Non-ECC,Un-buffered Memory
Triple channel memory architecture
- Expansion Slots:
2 x PCIe 2.0 x16 (dual at x16/x16 mode)
1 x PCIe x16 (at x4 mode)
2 x PCIe x1
1 x PCI
- Multi-GPU Support: Supports NVIDIA® Quad-GPU SLI™ techmology & Supports ATI® Quad-GPU CrossFireX™ Technology
- Storage:
Intel ICH10R controller:
6 xSATA 3.0 Gb/s ports (black)
Intel Matrix Storage Technology Support RAID 0,1,5,10
Marvell® 9128 PCIe SATA6Gb/s controller:
2 xSATA 6Gb/s ports (gray)
Supports EZ Backup and SuperSpeed functions
JMicron® JMB362 SATA controller:
1 xPower eSATA 3Gb/s port (SATA On-the-Go)
1 xeSATA 3Gb/s port (SATA On-the-Go)
- LAN: Realtek® 8110SC Gigabit LAN controller featuring AI NET2
- IEEE 1394: VIA® VT6308P controller supports 2 x 1394a port(s) (one at midboard; one at back panel)
- Form Factor: ATX Form Factor 12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
